Real time tracking; Mobile & Desktop APP; geofence, immobilizer, speed, reports, vibration/tow away, alerts & notifications.

echnical Specifications

GPS Specification

• GPS chipset: MTK high sensitivity chip
• Frequency : L1,1575.42MHz C/A code
• GPS channel:66
• Location accuracy : <10 meters
• Tracking sensitivity:-162dBm
• Acquisition sensitivity : -148dBm
• TTFF (open sky) : Avg. hot start≤1sec Avg. cold start≤35sec

Functional Specification

• Battery : mAh/3.7V Li-Polymer battery
• Working voltage/current : 9-90VDC/7mA（60VDC）
• GPS channel:66
• Location accuracy:<10 meters
• Tracking sensitivity:-165dBm
• Acquisition sensitivity:-148dBm
• TTFF (open sky):Avg. hot start≤1sec Avg. cold start≤32sec

Others

• Antenna:Bullit-in GPS antenna, GSM
• Battery:100mAh/3.7v lithium-polymer
• Working voltage/current:9-90VDC/8mA(36VDC)
• Standby time : 60 hours
• Working time : 4 hours
• Operating temperature : -20℃～ 70℃
• Device dimension : 78 .0(L)*41.0(W)*13.0(H)mm
• Device weight : 41g
